For the modern farmer the most important thing is to harvest all crops efficiently and as fast as possible without losses.
To achieve these goals we have focused our development around the following specific points:

• Weight optimization while increasing stability for cutting widths up to 18,5 m
• Absolute continuous material flow to the threshing elements of the combine
• Harvesting of different crops without setup times
• Intelligent cutter bar adjustment to ground contours
• Minimizing losses on the cutting table
• Precise cutting of the crop to the desired height
• Efficient and safe transport of the machines both on the road and in the field
• Incomparable life time



The development of BISO harvesting machines is comparable to tuning a car.
The combine manufacturers supply the solid base model – We make it into a winning “racing machine“, which fulfils
specific customer requirements perfectly.































SPECIFICATION (MY2020)



BISO 580 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 580 Header	–	*	*
hybrid header frame	–	o	o
header angle adjustment hydraulic	–	o	o
header angle adjustment with intelligent autonomous adaption	–	–	–
splash guard	–	–	–
water tank integrated	–	o	o
oil & hydraulic tank with indicator (integrated)	–	o	o
central lubrication for chain	–	*	o
integrated foldable side knives with deflectors right & left	–	*	*
side knives with 2-point slide bearing	–	o	o
headlights left and right	–	o	o
automatic hose reel 11 m for air pressure in combination with air compressor	–	–	–
toolbox with tool- and wear package	–	*	o
800 mm variomovement (distance knife – auger 180 mm)	–	o	o
parallelogram controlled flexarms – constant cutting angle	–	o	o
air suspension for Flexmode	–	o	o
air compressor with air dryer, compressed air tank & air filter	–	o	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	o	o
high wear resistant flex skids with rapid change system	–	o	o
left & right hand knife drive (gear box)	–	–	–
stainless steel vario floor covering	–	o	o
stainless steel flex area covering	–	o	o
integrated hydraulic reel drive	–	o	o
springsteel reel tines with rapid change system	–	o	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	–	o	–
wrapping protection for reel tine tube	–	o	o
reel tine angle adjustment	–	*	o
stainless steel auger Ø 660 mm instead of steel	–	*	*
intake auger with rapid height adjustment	–	o	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	–	–	–
crop lifters	–	–	–
dividers with rapid adjustment	–	o	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 680 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 680 Header	–	*	*
hybrid header frame	–	o	o
header angle adjustment hydraulic	–	o	o
header angle adjustment with intelligent autonomous adaption	–	–	–
splash guard	–	*	o
water tank integrated	–	o	o
oil & hydraulic tank with indicator (integrated)	–	o	o
central lubrication for chain	–	*	o
integrated foldable side knives with deflectors right & left	–	*	*
side knives with 2-point slide bearing	–	o	o
headlights left and right	–	o	o
automatic hose reel 11 m for air pressure in combination with air compressor	–	–	–
toolbox with tool- and wear package	–	o	o
800 mm variomovement (distance knife – auger 180 mm)	–	o	o
parallelogram controlled flexarms – constant cutting angle	–	o	o
air suspension for Flexmode	–	o	o
air compressor with air dryer, compressed air tank & air filter	–	o	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	o	o
high wear resistant flex skids with rapid change system	–	o	o
left & right hand knife drive (gear box)	–	–	–
stainless steel vario floor covering	–	o	o
stainless steel flex area covering	–	o	o
integrated hydraulic reel drive	–	o	o
springsteel reel tines with rapid change system	–	o	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	–	o	–
wrapping protection for reel tine tube	–	o	o
reel tine angle adjustment	–	*	o
stainless steel auger Ø 660 mm instead of steel	–	*	*
intake auger with rapid height adjustment	–	o	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	–	–	–
crop lifters	–	–	–
dividers with rapid adjustment	–	o	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 770 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 770 Header	*	*	*
hybrid header frame	o	o	o
header angle adjustment hydraulic	*	o	o
header angle adjustment with intelligent autonomous adaption	–	–	o
splash guard	*	*	o
water tank integrated	o	o	o
oil & hydraulic tank with indicator (integrated)	o	o	o
central lubrication for chain	*	*	o
integrated foldable side knives with deflectors right & left	*	*	*
side knives with 2-point slide bearing	o	o	o
headlights left and right	*	o	o
automatic hose reel 11 m for air pressure in combination with air compressor	*	*	*
toolbox with tool- and wear package	*	*	o
800 mm variomovement (distance knife – auger 180 mm)	o	o	o
parallelogram controlled flexarms – constant cutting angle	–	o	o
air suspension for Flexmode	–	o	o
air compressor with air dryer, compressed air tank & air filter	*	o	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	o	o
high wear resistant flex skids with rapid change system	–	o	o
left & right hand knife drive (gear box)	–	–	–
stainless steel vario floor covering	o	o	o
stainless steel flex area covering	–	o	o
integrated hydraulic reel drive	o	o	o
springsteel reel tines with rapid change system	o	o	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	o	o	o
wrapping protection for reel tine tube	o	o	o
reel tine angle adjustment	*	*	o
stainless steel auger Ø 660 mm instead of steel	*	*	*
intake auger with rapid height adjustment	o	o	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	*	*	*
crop lifters	*	–	–
dividers with rapid adjustment	o	o	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 920 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 920 Header	*	*	*
hybrid header frame	o	o	o
header angle adjustment hydraulic	*	o	o
header angle adjustment with intelligent autonomous adaption	–	–	o
splash guard	*	*	o
water tank integrated	o	o	o
oil & hydraulic tank with indicator (integrated)	o	o	o
central lubrication for chain	*	*	o
integrated foldable side knives with deflectors right & left	*	*	*
side knives with 2-point slide bearing	o	o	o
headlights left and right	*	*	o
automatic hose reel 11 m for air pressure in combination with air compressor	*	*	*
toolbox with tool- and wear package	*	o	o
800 mm variomovement (distance knife – auger 180 mm)	o	o	o
parallelogram controlled flexarms – constant cutting angle	–	o	o
air suspension for Flexmode	–	o	o
air compressor with air dryer, compressed air tank & air filter	*	o	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	o	o
high wear resistant flex skids with rapid change system	–	o	o
left & right hand knife drive (gear box)	o	o	o
stainless steel vario floor covering	o	o	o
stainless steel flex area covering	–	o	o
integrated hydraulic reel drive	o	o	o
springsteel reel tines with rapid change system	o	o	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	o	o	–
wrapping protection for reel tine tube	o	o	o
reel tine angle adjustment	*	*	o
stainless steel auger Ø 660 mm instead of steel	*	*	*
intake auger with rapid height adjustment	o	o	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	*	*	*
crop lifters	*	–	–
dividers with rapid adjustment	o	o	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 1070 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 1070 Header	*	*	*
hybrid header frame	o	o	o
header angle adjustment hydraulic	*	o	o
header angle adjustment with intelligent autonomous adaption	–	–	o
splash guard	*	*	o
water tank integrated	o	o	o
oil & hydraulic tank with indicator (integrated)	o	o	o
central lubrication for chain	o	o	o
integrated foldable side knives with deflectors right & left	*	*	*
side knives with 2-point slide bearing	o	o	o
headlights left and right	*	*	o
automatic hose reel 11 m for air pressure in combination with air compressor	*	*	*
toolbox with tool- and wear package	*	o	o
800 mm variomovement (distance knife – auger 180 mm)	o	o	o
parallelogram controlled flexarms – constant cutting angle	–	o	o
air suspension for Flexmode	–	o	o
air compressor with air dryer, compressed air tank & air filter	*	o	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	o	o
high wear resistant flex skids with rapid change system	–	o	o
left & right hand knife drive (gear box)	o	o	o
stainless steel vario floor covering	o	o	o
stainless steel flex area covering	–	o	o
integrated hydraulic reel drive	o	o	o
springsteel reel tines with rapid change system	o	o	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	o	o	–
wrapping protection for reel tine tube	o	o	o
reel tine angle adjustment	o	o	o
stainless steel auger Ø 660 mm instead of steel	*	*	*
intake auger with rapid height adjustment	o	o	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	*	*	*
crop lifters	*	–	–
dividers with rapid adjustment	o	o	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 1230 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 1230 Header	*	–	*
hybrid header frame	o	–	o
header angle adjustment hydraulic	*	–	o
header angle adjustment with intelligent autonomous adaption	–	–	o
splash guard	o	–	o
water tank integrated	o	–	o
oil & hydraulic tank with indicator (integrated)	o	–	o
central lubrication for chain	o	–	o
integrated foldable side knives with deflectors right & left	*	–	*
side knives with 2-point slide bearing	o	–	o
headlights left and right	o	–	o
automatic hose reel 11 m for air pressure in combination with air compressor	*	–	o
toolbox with tool- and wear package	o	–	o
800 mm variomovement (distance knife – auger 180 mm)	o	–	o
parallelogram controlled flexarms – constant cutting angle	–	–	o
air suspension for Flexmode	–	–	o
air compressor with air dryer, compressed air tank & air filter	*	–	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	–	o
high wear resistant flex skids with rapid change system	–	–	o
left & right hand knife drive (gear box)	o	–	o
stainless steel vario floor covering	o	–	o
stainless steel flex area covering	–	–	o
integrated hydraulic reel drive	o	–	o
springsteel reel tines with rapid change system	o	–	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	o	–	–
wrapping protection for reel tine tube	o	–	o
reel tine angle adjustment	o	–	o
stainless steel auger Ø 660 mm instead of steel	o	–	o
intake auger with rapid height adjustment	o	–	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	*	–	*
crop lifters	*	–	–
dividers with rapid adjustment	o	–	o

o – standard equipment       –  not available      * – contact us for price offer





BISO 1560 HEADER:

	BISO 2D VARIO	BISO 3D VARIOFLEX AIR	BISO 3D VARIOFLEX •AIR•i
BISO 1560 Header	*	–	*
hybrid header frame	o	–	o
header angle adjustment hydraulic	*	–	o
header angle adjustment with intelligent autonomous adaption	–	–	o
splash guard	o	–	o
water tank integrated	o	–	o
oil & hydraulic tank with indicator (integrated)	o	–	o
central lubrication for chain	o	–	o
integrated foldable side knives with deflectors right & left	*	–	*
side knives with 2-point slide bearing	o	–	o
headlights left and right	o	–	o
automatic hose reel 11 m for air pressure in combination with air compressor	*	–	o
toolbox with tool- and wear package	o	–	o
800 mm variomovement (distance knife – auger 180 mm)	o	–	o
parallelogram controlled flexarms – constant cutting angle	–	–	o
air suspension for Flexmode	–	–	o
air compressor with air dryer, compressed air tank & air filter	*	–	o
intelligent ground contour Flexarm control 0–50 kg	–	–	o
automatic locking rigidmode – Flexmode	–	–	o
high wear resistant flex skids with rapid change system	–	–	o
left & right hand knife drive (gear box)	o	–	o
stainless steel vario floor covering	o	–	o
stainless steel flex area covering	–	–	o
integrated hydraulic reel drive	o	–	o
springsteel reel tines with rapid change system	o	–	o
intelligent collision control knife / reel tines	–	–	o
mechanic collision safety for knife / reel tines	o	–	–
wrapping protection for reel tine tube	o	–	o
reel tine angle adjustment	o	–	o
stainless steel auger Ø 660 mm instead of steel	o	–	o
intake auger with rapid height adjustment	o	–	o
display for cab with real time flex movement	–	–	o
wifi communication – cab/header	–	–	o
2 in 1 swath deposit	*	–	*
crop lifters	o	–	–
dividers with rapid adjustment	o	–	o

o – standard equipment       –  not available      * – contact us for price offer



Trailers:

	580	680	770	920	1070	1230	1400	1600	1850
BISO Profi header trailer 2-axle	*	*	*	*	*	*	*	–	–
40 km/h version for Profi	*	*	*	*	*	*	*	–	–
BISO Profi Steer 2-axle four-wheel steering	–	–	*	*	*	*	*	*	*
40 km/h version for Profi	–	–	*	*	*	*	*	*	*



–  not available     * – contact us for price offer



Articles for this product:

BISO 2D – IN THE FIELD he BISO 2D VARIO series of combine headers is designed for high-performance combine harvesters that require perfect feeding of the harvested material under very different conditions. Drivers are exposed to considerable stress during harvest days in order to achieve high performance…

more info.

BISO 2D – PREFECT IN DETAILS  TThe BISO 2D VARIO series of combine headers covers working widths from 7.7 m to 15.6 m. This would not have been possible without the hybrid frame and other key technologies that make this range the market leader in headers with auger. In this article, let’s take a look…

more info.

BISO 2D VARIO The BISO 2D VARIO series of headers covers working widths from 7.7 m to 15.6 m. It is a typical representative of the BISO design school, i.e. the VARIO header with a powerful auger, with tip tilting and integrated side knifes. Of course, the hybrid frame cannot be missing at these working widths, and…

more info.



Gallery:





Video:



Brochure:

BISO 2D VARIO ENG

BISO 2D VARIO DE

BISO 2D VARIO FR

BISO 2D VARIO CZ



BISO 2D VARIO RU
